产品概述：

输出

输出功率容量                              300 瓦数 / 500 VA

z大可配置功率                          300 瓦数 / 500 VA

额定输出电压                              230V

满负载效率                                  95%

输出频率(与主频率同步)           47 - 53 Hz（50 Hz 标称值）

波峰因数                                      3 : 1

波形类型                                      正弦波逐步逼近

输出连接                                      (2) Chinese outlet (备用电池)

输入

额定输入电压                                    230V

输入频率                                            45 - 55 Hz

输入端子类型                                    Australian/Chinese

输出线长度                                        2.44米

工作电压范围                                    165 - 266V

其他输入电压                                    220

电池与运行时间

电池型号                                            VRLA

典型充电时间                                    24 小时

可更换电池包                                    RBC2

RBC? 数量                                      1

通讯与管理

控制面板                                            LED 状态显示“在线”、“电池开”

有声报警                                            市电停电时报警：特别的低电池报警overload continuous tone alarm

浪涌保护及滤波

浪涌抑制能量                                   180 焦耳

物理指标

高                                                       105.00 mm

宽                                                       295.00 mm

深                                                       174.00 mm

净重                                                   5.40 KG

运输重量                                           6.02 KG

运输高度                                           114.00 mm

运输宽度                                           381.00 mm

运输长度                                           178.00 mm

颜色                                                   木炭

SCC 代码                                         1073130422429 4

环境

工作环境                                           0 - 40 °C

工作相对湿度                                   10 - 90%

操作高度                                           0-999.9米

存储温度                                           -15 - 45 °C

存储相对湿度                                   5 - 95%

存储高度                                           0-4500米

听觉噪音距设备表面 1 m 处         40.00 dBA

相符性

标准质保                                          2年内维修或更换

环保要求遵从情况                          RoHS 7b Exemption,中国 RoHS,REACH: Contains No SVHCs

**UPS带50%额定容量负载放电至关机后，重新充电到90%电池容量所需时间 。
